Features
Line interactive UPS
Auto restart while AC is recovering
Double boost
Automatic voltage regulation (AVR)
Wide input range
Microcontroller based
Generator compatible
Specifications
Capacity
(VA/W) 650VA/360W
Input
Nominal voltage 220-240 VAC
Voltage range 140-300 VAC ± 7 Vac
Frequency 40-70 Hz ± 1 Hz
Plug type 3 Pin plug
Output
Voltage range (AC mode) 195-262Vac ±7Vac
Voltage range (Batt. mode 230VAC ± 10 %
Frequency range (Batt. mode) 50/60Hz ±1%
Transfer time 4ms TYP
Waveform Simulated sine wave
No. of output sockets 3
Protections Overload, Short circuit, Over discharge & Over charge
Battery
Battery type 12V 7Ah x 1 no
Charging current 12V 7Ah x 1 no
Recharge time 4 hours to charge 90%
Indicators
No. of LEDs 1 LED
AC mode Green lighting
Battery mode Green flashing
Alarm
Battery mode Beeping every 30 seconds
Low battery Beeping every 2 seconds
Overload Beeping every 0.5 seconds
Fault Continuous beeping
Physical details
Product dimension (W x D x H) 87 x 277 x 165 mm
Net. weight 4kg
Package dimension (WxDxH 319 x 126 x 232 mm
Environmental factors
Operational temperature 0-40⁰C
Noise level < 40dB
